Drilling depth: 190m
Drilling diameter: 75-500mm
Rated Power: 13.2kw
Drilling diameter: 75-500mm
Rated Power: 13.2kw
Crazy Engineering Days Sale, Submit Form to Get Order Discount and Off Coupon
Parameter
| model | HW190YY | |
| Drilling depth | 190 | m |
| Opening diameter | 500(Soil)/220(Rock) | mm |
| final hole diameter | 75 | mm |
| Drill pipe diameter | 42-50 | mm |
| Drilling angle | 90-75 | ° |
| Engine power | 13.2 | kw |
| weight | 900 | kg |
| Machine size | 2400*800*1400 | mm |
| Vertical shaft speed | 130/300/480/730/830/1045 | r/min |
| Vertical axis travel | 450 | mm |
| Single rope lifting force | 2100 | kg |
| Single rope lifting speed | 0.35-2.23 | m/s |
| Wire rope diameter | φ9.3 | mm |
| Wire rope capacity | 27 | m |
| Rated load | 18 | Ton |
| effective height | 6.5 | m |
| flow | 95 | L/Min |
| greatest pressure | 1.2 | Mpa |
| Optional configuration | Motor | |
Main features:
1.The water drilling machine is designed to be easily transportable, with options for tracking or trucking, allowing for flexibility in transportation methods.
2. The inclusion of high outriggers facilitates convenient loading and unloading operations, eliminating the need for a crane during the process.
3. The drilling rig is highly versatile, suitable for various applications such as water well drilling, mineral exploration, geothermal applications, soil surveys, rock coring, and more. Its wide range of uses makes it a versatile tool for different drilling needs.
To obtain the latest technical parameters and quotes for Hengwang water well drilling rigs, please fill out the form provided below. Our team will review your submission and provide you with the updated information. Thank you for your interest!
Shandong Hengwang Group Co., Ltd., as one of the top drilling machinery and piling machinery suppliers in China, has 20 years of experience in the production of drilling rigs and piling machines.
