Drilling depth: 300m
Drilling diameter: 75-350mm
Engine Power: 58Kw
Drilling diameter: 75-350mm
Engine Power: 58Kw
Main feature:
1. Reasonable power engine can save fuel while ensuring stable and high performance;
2. High-quality hydraulic components and strict assembly process ensure the high efficiency of the hydraulic system;
3. Using international high-standard raw materials to ensure the stability of the car body;
Parameter:
| Model | HWDL350 |
| Drilling depth | 300m (152mm~203mm) |
| Rope core-drilling 75mm bore diameter | 450~500m |
| Drilling diameter | Ø75～Ø350mm |
| Drilling angle | 90° |
| Mud pump | BW160/ BW200/ BW250 |
| Walking Speed | 0～2 km/h |
| Gradeability | Max. 25°~30° |
| Transport dimension | 5400*1600*2600mm |
| Working state dimension | 3480*1600*7300mm |
| Machine weight | 5800kg |
Due to the continuous update and progress of technology, technical parameters and configurations are subject to actual delivery.
Shandong Hengwang Group Co., Ltd., as one of the top drilling machinery and piling machinery suppliers in China, has 20 years of experience in the production of drilling rigs and piling machines.
