Drill diameter: 40-120mm
Drill depth: 30m
Related power: 42Kw
Drill depth: 30m
Related power: 42Kw
1. Drill rig pushes directly to make sampling
2. The drilling rig without rotary is not necessary to add water
3. It is to make samples with double tubes and sample reach directly into inner tube without contamination
4. It is equipped with leakproof plug and leakproof connecting rod to realize leakproof
5. It can make Max. 30m depth sampling
6. 120mm diameter sampling (sampling depth will be reduced)
| Model | HW180D |
| Size (L*W*H) | 3400*1500*2400mm |
| Drilling diameter | 40-120mm |
| Drilling depth | 30m |
| Drill pipe length | 3m |
| Walking speed | 2.5km/h |
| Working pressure | 1.45-2.5Mpa |
Due to the continuous update and progress of technology, the difference between the technical parameters and configuration and the actual product is subject to the actual delivery.
Submit the form to get the latest parameters and quotations.
Shandong Hengwang Group Co., Ltd., as one of the top drilling machinery and piling machinery suppliers in China, has 20 years of experience in the production of drilling rigs and piling machines.
