Drill Depth: 300m
Max.Drill Diameter: 254mm
Related Power: 92Kw
Max.Drill Diameter: 254mm
Related Power: 92Kw
Main features:
1. The pneumatic drilling rig works in conjunction with an air compressor, resulting in high working efficiency.
2. Enhanced stability through increased counterweight, ensuring strong work stability.
3. Perfect cooperation between the engine and hydraulic system, leading to reduced fuel consumption and improved fuel efficiency.
Parameter
| Model | HW3/160 |
| Drilling depth | 300m |
| Drilling diameter | Ø76, Ø89, Ø102mm |
| Lifting force | 160KN |
| Propulsive force | 80KN |
| Maximum torque | 18000N.m |
| Rated power / speed | 58kW/2400r/min |
| Transport dimension | 3980*3130*6500mm |
| Working state dimension | 3980*3130*6500mm |
Due to the continuous updates and advancements in technology, the technical parameters and configurations of the product are subject to change at the time of actual delivery.
Shandong Hengwang Group Co., Ltd., as one of the top drilling machinery and piling machinery suppliers in China, has 20 years of experience in the production of drilling rigs and piling machines.
